◆新產品特殊性 Product features
1. 設計構思大(da)氣(qi),內部結構美觀度,環境保護(hu)的體現效果;
2. 調節式颶風分離器,能(neng)將(jiang)該用金剛(gang)石工具磨具與(yu)小粉塵爆炸分離,好的(de)金剛(gang)石工具磨具以(yi)后實用;
3. 注意(yi)零元(yuan)件用到更優質原產所(suo)需(xu)要(yao)的零部件,安全使用生存(cun)期長(chang);
4. 制作鋁件表(biao)面能平(ping)均;
5. 多卡位設計的概念;運作員可而且運作噴砂。利用大家所需,待選擇帶有大量手動或自主 ;可按顧客必須為您加工定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆不設備適用領域之內 Applicable scope
石材,臺式機塑料外殼(ke),功放音響蓋板,漢堡包烤盤(pan)等剖(pou)面及方(fang)體產品(pin)的噴砂(sha)工(gong)藝。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆通常的技術運作 Main technical parameters
|
機氣主(zhu)要參(can)數 Model |
STR-多工位輸送式噴砂機 |
|
整套裝置(zhi)長(chang)寬 Complete machine size(mm) |
3000×1000×1700 |
|
工作中空間 Work space(mm) |
2000×1000×800 |
|
外氣力(li)輸送機盡寸 Conveying the size(mm) |
500×1000×1000(2件(jian)) |
|
降塵箱長寬高 Dedust box sizes(mm) |
600×600×1800 |
|
分離出來器交流電動(dong)機(ji) Separator motor |
220V 50HZ 550W |
|
分離法器(qi)風口尺寸(cun) Separator air volume |
8.5m3/min |
|
收縮廢(fei)氣(qi)源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W防燃燈 |
|
機器設(she)備權重 Machine weight |
550kg |
